Edge
TM
Multipoint and Quickbridge - Hardware Installation Guide 24
SNR Information (5.150 - 5.925) GHz
If DDRS is disabled, the user can configure the Data Rate values manually as per the reference table below.
MCS
Index
Modulation No.
of Streams
5.150 - 5.925 GHz
20 MHz
Full (GI = 800ns) Short (GI =400ns)
Data Rate Min SNR Max SNR Data Rate Min SNR Max SNR
MCS0 BPSK 1/2 Single 6.5 14 55 7.2 14 55
MCS1 QPSK 1/2 Single 13 15 55 14.4 15 55
MCS2 QPSK 3/4 Single 19.5 16 55 21.7 16 55
MCS3 16 QAM 1/2 Single 26 20 55 28.9 20 55
MCS4 16 QAM 3/4 Single 39 20 55 43.3 20 55
MCS5 64 QAM 2/3 Single 52 24 55 57.8 24 55
MCS6 64 QAM 3/4 Single 58.5 25 55 65 25 55
MCS7 64 QAM 5/6 Single 65 27 52 72.2 27 52
MCS8 256 QAM 3/4 Single 78 32 52 86.7 32 52
MCS9 256 QAM 5/6 Single 86.7 -NA- -NA- 96.0 -NA- -NA-
MCS0 BPSK 1/2 Dual 13 15 55 14.4 15 55
MCS1 QPSK 1/2 Dual 26 16 55 28.9 16 55
MCS2 QPSK 3/4 Dual 39 17 55 43.3 17 55
MCS3 16 QAM 1/2 Dual 52 23 55 57.8 23 55
MCS4 16 QAM 3/4 Dual 78 24 55 86.7 24 55
MCS5 64 QAM 2/3 Dual 104 26 55 115.6 26 55
MCS6 64 QAM 3/4 Dual 117 28 55 130 28 55
MCS7 64 QAM 5/6 Dual 130 29 50 144.4 29 50
MCS8 256 QAM 3/4 Dual 156 38 50 173.3 38 50
MCS9 256 QAM 5/6 Dual 173.3 -NA- -NA- 192.0 -NA- -NA-
