Edge
TM
Multipoint and Quickbridge - Hardware Installation Guide 22
Interfaces
Transmit Power Specifications (5.150 - 5.925) GHz
Products Category Specification
MP-1015-CPE
MP-1025-CPE
MP-1035-CPE
MP-1015-BS3
MP-1025-BS3
QB-1015-LNK
QB-1025-LNK
QB-1035-LNK
Wired Ethernet Auto MDI-X, auto configuration and fixed
speed/duplex configurations
One auto MDI-X RJ45 Gigabit Ethernet Port
with PoE IN and Data
Products Stream MCS
Index
Modulation
Type
Coding
Rate
Tx Power* (dBm)
VHT20
(5.15-5.95 GHz)
VHT40
(5.15- 5.95 GHz)
MP-1015-CPE
MP-1025-CPE
MP-1035-CPE
MP-1015-BS3
MP-1025-BS3
QB-1015-LNK
QB-1025-LNK
QB-1035-LNK
Single
stream
(or)
Dual
Stream
(or)
Quad
Stream
MCS 0
BPSK
1/2
21 20
MCS 1
QPSK
1/2
21 20
MCS 2
QPSK
3/4
20 19
MCS 3
16QAM
1/2
20 19
MCS 4
16QAM
3/4
19 18
MCS 5
64QAM
2/3
19 18
MCS 6
64QAM
3/4
17 17
MCS 7
64QAM
5/6
17 16
MCS 8
256-QAM
3/4
16 15
MCS 9
256-QAM
5/6
NA 15
Note:
• Output Power Attenuation: 0 – 21 dB, in 1 dB steps
• For MCS 0, the maximum attenuation limit is 17 dB
• For MCS 9, the maximum attenuation limit is 10 dB
• Total EIRP must be calculated based on the antenna gain
• Tolerance = +/- 2 dB
* Tx Power indicates the power at the radio ports.
* In case of integrated devices, the Tx Power at the antenna ports is 1 dB higher than the above tabulated values.
• In the FCC United States 5.8 GHz band edge frequencies, the Maximum Tx Power of the radio will be restricted based on the FCC
Certification and Antenna Type used. For details refer the Antenna Intallation and Recommendation Guide.
