Proxim Edge MP-1015-CPE User Manual

Technical Specifications
Edge
TM
Multipoint and Quickbridge - Hardware Installation Guide 26
Power Supply
Hardware Specifications
Physical Specifications
Products Category Specification
MP-1015-CPE
MP-1025-CPE
MP-1035-CPE
MP-1015-BS3
MP-1025-BS3
QB-1015-LNK
QB-1025-LNK
QB-1035-LNK
Input Voltage Via RJ45 Ethernet interface supplying 56 V DC on Ethernet Port.
Power consumption: 16 W typical, 18 W max (1015 & 1025)
10 W typical, 12 W max (1035)
PoE Injector Input: 100 – 240 V AC (50/60 Hz)
Output: 56 V DC (30 Watts)
*Pin-out: V+ on pins 3/4/5/6, V- on pins 1/2/7/8
Operating Temp: 0º C to +40º C
* Refer supplied PoE model for actual power Pin-out specification.
Products Radio Processor
Speed
Memory Input Power Power Consumption
MP-1015-CPE
MP-1025-CPE
MP-1035-CPE
MP-1015-BS3
MP-1025-BS3
QB-1015-LNK
QB-1025-LNK
QB-1035-LNK
5.150 - 5.925 GHz
MIMO radio
720 MHz Flash: 32 MB
RAM: 256 MB
Power-over-Ethernet
56V DC / (0.536) A
16 W typical, 18 W
max (1015 & 1025).
10 W typical, 12 W
max (1035)
Products Category Specification
MP-1015-CPE
MP-1025-CPE
MP-1035-CPE
MP-1015-BS3
MP-1025-BS3
QB-1015-LNK
QB-1025-LNK
QB-1035-LNK
Dimensions (L x W x H) 170 x 217 x 56 mm / 6.7 x 8.55 x 2.2 in
Weight MP-1015: 1.24 kg / 2.73 lbs
MP-1025: 1.24 kg / 2.73 lbs
MP-1035: 1.19 kg / 2.62 lbs

Proxim Edge MP-1015-CPE Specifications

General

Brand	Proxim
Model	Edge MP-1015-CPE
Category	Wireless Access Point
Language	English
