Edge
TM
Multipoint and Quickbridge - Hardware Installation Guide 21
OFDM Modulation Rates
Given below are the OFDM modulation rates for the Edge
TM
products:
Wireless Protocol
MCS
Index
Modulation Coding
Rate
Data Rates (Mbps) Per Stream
20 MHz Channels 40 MHz Channels
800ns GI 400ns GI 800ns GI 400ns GI
0 BPSK 1/2 6.5 7.2 13.5 15
1 QPSK 1/2 13 14.4 27 30
2 QPSK 3/4 19.5 21.7 40.5 45
3 16QAM 1/2 26 28.9 54 60
4 16QAM 3/4 39 43.3 81 90
5 64QAM 2/3 52 57.8 108 120
6 64QAM 3/4 58.5 65 121.5 135
7 64QAM 5/6 65 72.2 135 150
8 256-QAM 3/4 78 86.7 162 180
9 256-QAM 5/6 N/A N/A 180 200
Note:
• Maximum Packet Size = 9000 Bytes (excluding one VLAN header, Ethernet header and FCS).
Category Specification
Wireless Protocol WORP
®
(Wireless Outdoor Router Protocol)
