Multipoint and Quickbridge - Hardware Installation Guide 33
7.5.1 Sector Antenna Specifications
• 14 dBi Dual Polarized Sector Antenna
• 15.5 dBi Dual Polarized Sector Antenna
7.5.1.1 14 dBi Dual Polarized Sector Antenna
Electrical Specifications
Environmental and Mechanical Specifications
Frequency Range 4.9 GHz - 5.95 GHz
Gain 14 dBi (min)
VSWR 2:1 (max) 1.7: 1 (typ)
Azimuth Beam Width
• Port V
• Port H
90° (typ) @11dBi Gain
90° (typ) @10dBi Gain
3dB Elevation Beam width 8º (typ)
Polarization Linear, Vertical and Horizontal
Cross Polarization -25 dB (type), -15 dB (max)
F/B Ratio 25 dB (min)
El Side lobes Level -10 dB (typ)
Port To Port Isolation 30 dB (min)
Input Impedance 50 Ohms
Input Power 20 W (max)
Lightning Protection DC Grounded
Wind Survival 220 km/hr
Temperature Range -45 to +70 °C
Humidity 95%
Water Tightness IP67
Dimension (L x W x H) 500 x 200 x 30 mm
Weight 1.5 kg (max)
Connectors 2 x N-type female
Radome Material Plastic
Radome Thickness 2.0 ± 0.2 mm
