Multipoint and Quickbridge - Hardware Installation Guide 35
7.5.1.2 15.5 dBi Dual Polarized Sector Antenna
Electrical Specifications
Environmental and Mechanical Specifications
Frequency Range 4.9 GHz - 6.0 GHz
Gain 15.5 dBi (typ)
VSWR 2:1 (max) 1.7: 1 (typ)
3 dB Azimuth Beam Width 60° (typ)
3dB Elevation Beam width 8º (typ)
Polarization Linear, Vertical and Horizontal
Cross Polarization -15 dB (typ)
F/B Ratio 20 dB (max)
El Side lobes Level -10 dB (typ)
Port To Port Isolation 22 dB (min) 25 dB (typ)
Input Impedance 50 Ohms
Input Power 20 W (max)
Lightning Protection DC Grounded
Wind Survival 220 km/hr
Temperature Range -45 to +70 °C
Humidity 95%
Water Tightness IP67
Dimension (L x W x H) 500 x 200 x 30 mm
Weight 1.5 kg (max)
Connectors 2 x N-type female
Radome Material Plastic
Radome Thickness 2.0 ± 0.2 mm
