Technical Specifications

Edge

Multipoint and Quickbridge - Hardware Installation Guide 23

Receive Sensitivity (5.150 - 5.925) GHz

Products Stream Modulation Type Coding Rate

Receive Sensitivity*

(dBm)

(5.150 ~ 5.875) GHz

VHT20 VHT40

MP-1015-CPE

MP-1025-CPE

MP-1035-CPE

MP-1015-BS3

MP-1025-BS3

QB-1015-LNK

QB-1025-LNK

QB-1035-LNK

Dual Stream

BPSK

1/2 -91 -87

QPSK

1/2 -87 -84

QPSK

3/4 -85 -82

16 QAM

1/2 -83 -79

16 QAM

3/4 -78 -75

64 QAM

2/3 -74 -72

64 QAM

3/4 -72 -70

64 QAM

5/6 -70 -67

256QAM

3/4 -68 -64

256QAM

5/6 -66 -62

Note:

• Receive Sensitivity values should be considered with a tolerance +/- 2 dB.
