Multipoint and Quickbridge - Hardware Installation Guide 25
MCS
Index
Modulation No
of
Streams
5.150 - 5.925 GHz
40 MHz 80 MHz
Full (GI = 800ns) Short (GI = 400ns) Full (GI = 800ns) Short (GI = 400ns)
Data
Rate
Min
SNR
Max
SNR
Data
Rate
Min
SNR
Max
SNR
Data
Rate
Min
SNR
Max
SNR
Data
Rate
Min
SNR
Max
SNR
MCS0 BPSK 1/2 Single 13.5 14 55 15 14 55 29.3 23 55 32.5 23 55
MCS1 QPSK 1/2 Single 27 15 55 30 15 55 58.5 23 55 65 23 55
MCS2 QPSK 3/4 Single 40.5 16 55 45 16 55 87.8 23 55 97.5 23 55
MCS3 16 QAM 1/2 Single 54 20 55 60 20 55 117 25 55 130 25 55
MCS4 16 QAM 3/4 Single 81 20 55 90 20 55 175.5 26 55 195 26 55
MCS5 64 QAM 2/3 Single 108 24 55 120 24 55 234 28 55 260 28 55
MCS6 64 QAM 3/4 Single 121.5 25 55 135 25 55 263.3 31 55 292.5 31 55
MCS7 64 QAM 5/6 Single 135 29 50 150 29 50 292.5 34 50 325 34 50
MCS8 256 QAM 3/4 Single 162 32 50 180 32 50 351 36 50 390 36 50
MCS9 256 QAM 5/6 Single 180 34 50 200 34 50 390 38 50 433.3 38 50
MCS0 BPSK 1/2 Dual 27 14 55 30 14 55 58.5 23 55 65 23 55
MCS1 QPSK 1/2 Dual 54 16 55 60 16 55 117 23 55 130 23 55
MCS2 QPSK 3/4 Dual 81 18 55 90 18 55 175.5 23 55 195 23 55
MCS3 16 QAM 1/2 Dual 108 20 55 120 20 55 234 25 55 260 25 55
MCS4 16 QAM 3/4 Dual 162 22 55 180 22 55 351 26 55 390 26 55
MCS5 64 QAM 2/3 Dual 216 28 55 240 28 55 468 28 55 520 28 55
MCS6 64 QAM 3/4 Dual 243 31 55 270 31 55 526.5 31 55 585 31 55
MCS7 64 QAM 5/6 Dual 270 33 50 300 33 50 585 35 50 650 35 50
MCS8 256 QAM 3/4 Dual 324 39 50 360 39 50 702 38 50 780 38 50
MCS9 256 QAM 5/6 Dual 360 41 50 400 41 50 780 38 50 866.6 38 50
