Step 14: Weatherproof the Connectors
After you have fully assembled and tightened the cable, use the provided
self-fusing, rubber-based tape strip and electrical tape (not provided; Proxim
recommends Scotch™ Super 33+ Vinyl Electrical Tape) to seal the connection,
as follows.
Remove the lm liner from the rubber-based tape strip, and stretch the
tape until it is approximately half of its original width. This activates the
self-fusing action of the tape, which will set up over time to create a single,
waterproof mass.
Stretch and wrap the tape around the connector tightly, starting below the
connector cap and against the unit and wrapping in a clockwise direction.
Wrap the tape once around the base of the connector cap (A). Continue
to wrap the tape spirally around the connector in a clockwise direction,
maintaining a 50% width overlap (B). Continue wrapping the tape spirally
upward (C) until the tape extends onto the cable and you have used the
entire length of tape. Seal the tape tightly against the connector and the
cable (D).
Note:
Be sure to wrap the tape in a clockwise direction; wrapping the tape in a
counterclockwise direction may loosen up the connector.
In the same manner as described in Step 2 above, apply a layer of black
electrical tape (not provided) over the rubber-based tape for further
protection. Make sure the electrical tape also extends beyond the rubber-
based tape to seal it.
Repeat the weatherproong procedure for other connectors as appropriate.
1.
2.
3.
4.
