PS Engineering
PAC45 Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-045-0000 Page 1-5 Rev. 7, May 2019
PAC45 Retrofit Installation Kit: 250-045-0100
Description
PS E
Part Number
Quantity
Manufacturer
MFR Part Number
D-Sub housing 9 pin female
425-009-7709
1
Amphenol
L177-RR-E-09-S
D-sub Pins Male
425-020-5089
9
Deutsch
M39029/64-369
D-sub Pins Female
425-020-5090
9
Deutsch
M39029/63-368
D-Sub housing 26 pin female
425-026-1800
2
NorComp
180-026-273L000
Socket contact 22-28 AWG
425-030-7354
52
Amphenol
M39029/57-354
D-Sub Latch slide clip
475-045-5206
4
Tyco Electronics
5206942-1
Backshell DB9
625-009-5750
1
Tyco Electronics
5750100-1
Backshell DB26
625-015-5206
2
Tyco Electronics
5206478-2
HUB45R Remote Hub Retrofit Installation Kit: 250-045-0200
Description
PS E
Part Number
Qty.
Manufacturer
MFR Part Number
D-Sub housing 9 pin male
425-009-0777
1
Amphenol
L777-RR-E-09-P
D-sub Pins Male
425-020-5089
9
Deutsch
M39029/64-369
Backshell DB9
625-009-1724
1
Amphenol
17E-1724-1
Thumbscrew
475-002-0002
2
Lanpar Technologies,
Inc.
B71E014256
HUB45 Installation Kit 250-945-0100
Description
PS E
Part Number
Quantity
Manufacturer
MFR Part Number
15/26 pin connector backshell
625-015-1725
2
Amphenol
17E-1725-1
DB26 Female Connector HD
425-026-1800
2
NorComp
180-026-273L000
Female Socket
425-030-7354
52
Amphenol
M39029/57-354
Thumbscrew
475-002-0002
2
Lanpar Tech-
nologies, Inc.
B71E014256
Slide Lock Post*
475-045-6514
4
TE
5206514-6
*See §2.3.4
