PS Engineering
PAC45 Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-045-0000 Page 1-6 Rev. 7, May 2019
Remote Mount HUB45R retrofit Installation Kit 250-045-0300
Description
PS E
Part Number
Qty.
Manufacturer
MFR Part Number
9-Pin Male D-Sub Housing
425-009-0777
1
Amphenol
L777-RR-E-09-P
D-Sub male pins
425-020-5089
9
Deutsch
M39029/64-369
9-Pin D-Sub Female Housing
425-009-7709
1
Amphenol
L777-RR-E-09-S
D-Sub Female sockets
425-020-5090
9
Deutsch
M39029/64-368
Remote Mounting Flange LEFT
430-045-0120
1
PS Engineering
Remote Mounting Flange RIGHT
430-045-0125
1
PS Engineering
4-40 x 3/16” Phil-Pan w/EXT Star
Washer
475-440-0500
8
4-40 x 3/16” Phil-Flat Gold + Patch
Counter Sunk
475-442-2001
12
Connector Backshell DB9 Plastic
MODIFIED
625-009-1724
1
PS Engineering
Connector Backshell DB9 Plastic NON-
MODIFIED
625-009-1724
Thumbscrew
475-002-0002
2
Lanpar Tech-
nologies, Inc.
B71E014256
EQUIPMENT REQUIRED BUT NOT SUPPLIED
a. Circuit Breakers: 1 ea.; 1 amp PULL TYPE REQUIRED for PAC45, .05 A for CTL45s
b. Optional Circuit Breaker: 0.5 ea.; 1 amp PULL TYPE REQUIRED for PAC45 aural alerts
c. Headphone Jacks (Stereo, as Required)
d. Microphone Jacks (as Required)
e. Headphones, 150 (Stereo), as required
f. Microphones, as required
g. Interconnect Wiring
