PSG Caddy PF01010 - Technical Data Caddy; General Technical Data

48
 CADDY WOOD ONLY
3.2.5 TECHNICAL DATA CADDY
CADDY CADDY
A
48”
F
24 9/16”
B
26”
G
43 1/2”
C
47 13/16”
FLUE
* 6"
D
15 3/4” X 24 3/4”
WEIGHT
590 lb
E
28 9/16”
* If desired, to allow the retrofit to wood/oil configuration, we suggest the use of
a 7” chimney, this way you wouldn’t have to change the chimney. In that case,
a 6” to 7” reducer must be installed at the flue outlet of the furnace.
3.2.5.1 GENERAL TECHNICAL DATA
MODEL (DIRECT DRIVE) DEBIT
TEMP
VAR.
BTU/ H
STATIC
PRESSURE
FILTER
VENT MOT. VIT. (CFM) (OF) (BOIS) MIN. MAX. (2)
H2O
CADDY DD-10 1/3 4 1300 78 140000 0,2 0,5 25” x 14” x 1”
