3.4.8 CADDY TECHNICAL DATA
CADDY WOOD/OIL CADDY WOOD/OIL
A
48”
G
43 1/2”
B
26”
H
** 34 3/16”
C
47 13/16”
I
56 1/16”
D
15 3/4” X 24 3/4”
J
33 13/16”
E
28 9/16”
FLUE
* 7"
F
24 9/16”
WEIGHT
** 590 lb
* A 6” to 7” reducer must be installed at the flue outlet of the furnace.
** Does not include the oil burner (sold separately).
MODEL BURNER
TYPE
BTU
INPUT
NOZZLE HEAD STATIC
PLATE
PRESSURE
AT THE PUMP
H.P. FAN
MOTOR
CADDY BECKETT
AFG
91,000 0.65, 70
O
W
(DELAVAN)
F3 2 3/4 120 PSI 1/3 H.P.
CADDY RIELLO/F3 91,000 0.65, 70
O
W
(DELAVAN)
--- --- 120 PSI 1/3 H.P.
CADDY AERO/FAF
C-2X
91,000 0.65, 70
O
W
(DELAVAN)
--- --- 120 PSI 1/3 H.P.
For any additional information, consult the certification plate on the left hand side
of the appliance.
