9 PART H - SPECIFICATIONS
Optional electric unit
Heat output – recommended electric unit 18 kW
Heat output – other optional electric unit 15, 20 kW
Unit location Left
Unit’s recommended service clearance 24”
Cadd
wood onl
furnace
Combustible Wood
Maximum heat input 140,000 BTU (41 kW)
Maximum heat output 106,400 BTU (31,2 kW)
Average heat output 69,160 BTU (20,3 kW)
Thermostatic control Yes
Maximum efficiency 76% (LHV) / 71% (HHV)
Average emissions 6.6 grams/hr ou 0,229 g/MJ
Loading capacity Up to 55 lb (25 kg)
Flue outlet size 6” (152 mm)
Recommended smoke pipe dimension
6“ If installed in wood only and wood-electric
7” If installed in wood-oil
Recommended chimney type 2100 °F (1150 °C)
Recommended chimney size
6“ If installed in wood only and wood-electric
7” If installed in wood-oil
Outside dimensions of the furnace 26”L x 47”P x 48”H
Dimensions of the firebox 17”L x 22,5”P x 16”H
Dimensions of the door opening 13,75”L x 10”H
Type of door Cast iron with ceramic glass
Dimensions of the hot air plenum 24,5”L x 28,25”
Dimensions of the cold air plenum 24,5”L x 15,75”
Dimensions of ash drawer 12”L x 16”P x 3”H
Thickness of steel (firebox) 3/16” (5 mm)
Minimum clearance (in front of furnace) 48”
Minimum clearance (rear of furnace ) 24” recommended service clearance
Minimum clearance (sides of furnace ) 24” recommended service clearance
Minimum clearance (standard ducts) 6” for the first 6 feet and 1” after
Recommended service clearance 24”
Weight 590 lb (268 kg), with blower
Color Green
Warranty Limited lifetime
Standards – security
Can CSA B366.1-M91, CSA C22.2 No. 236, UL
1995, UL391 3rd Ed. rev. 1999
Standards – emissions / efficiency EPA / CSA B415.1
Maximum log length 22””
