Pullnet AGENT-2 S41D Line - Functional Description

AGENTSSR/AGENT-2 S41D Line - User Manual AG2-S41D/MU-EE
Ed. Jul-2012 Proprietary information 3 of 89
Power Input Assignment
Power3
12VDC
DC Jack
Power2
󶁛
12-
48VDC
Terminal
Block
󶁝
Power
Ground
Power1
󶁛
12-
48VDC
󶁝
Power
Ground
Earth
Ground
Relay Output Rating
1A @
24VDC
Relay Alarm Assignment
FAULT
*Warning signal disable for
following:
The relay contact closes if
Power1 and Power2 are
both failed but Power3 on.
The relay contact closes if
Power3 is failed but
Power1 and Power2 are
both on.
1.2 Functional Description
 Complies with IEC61850-3 & IEEE1613 environmental requirements for power
substation automation systems.
 Complies with EN50121-4 environmental requirements for railway applications.
 Meets EN61000-6-2 & EN61000-6-4 EMC Generic Standard Immunity for
industrial environment.
 Manageable via SNMP, Web-based, Telnet, and RS-232 console port.
 Supports Command Line Interface in RS-232 console.
 Supports 802.3/802.3u/802.3ab/802.3z/802.3x. Auto-negotiation:
10/100/1000Mbps, full/half-duplex; Auto MDI/MDIX.
