 100Base-FX: Multi mode SC or ST type, Single mode SC or ST type. 100Base-
BX: WDM Single mode SC type.
 1000Base-SX/LX: Multi mode or Single mode SC type. 1000Base-BX: WDM
Single mode SC type.
 Supports 8192 MAC addresses. Provides 2M bits memory buffer.
 Store-and-forward mechanism. Full wire-speed forwarding rate.
 Alarms for power and port link failure by relay output.
 Power Supply: Redundant DC Terminal Block power inputs and 12VDC DC JACK
with 100-240VAC external power supply.
 Operating voltage and Max. current consumption: 1.25A @ 12VDC, 0.625A @
24VDC, 0.313A @ 48VDC. Power consumption: 15W Max.
 Tested for functional operation @ -40 ºC to 80 ºC.
 Supports DIN-Rail or Panel Mounting installation.
1.3 Console Configuration
 Connect to the switch console:
 Connect the DB9 straight cable to the RS-232 serial port of the device and the
RS-232 serial port of the terminal or computer running the terminal emulation
application. Direct access to the administration console is achieved by directly
connecting a terminal or a PC equipped with a terminal-emulation program (such
as HyperTerminal) to the switch console port.
 Configuration settings of the terminal-emulation program:
 Baud rate: 115,200bps
 Data bits: 8
 Parity: none
 Stop bit: 1
 Flow control: none
