AGENT-2 S41D Line - User Manual AG2-S41D/MU-EE
Ed. Jun-2012 Proprietary information 64 of 89
SNMPv3 No-Auth: Add a user using SNMP v3 without authentication.
SNMPv3 Auth-MD5: Add a user using SNMP v3 with authentication. Click on
the “Auth. Password” textbox and specify an authentication password.
SNMPv3 Auth-SHA: Add a user using SNMP v3 with authentication. Click on
the “Auth. Password” textbox and specify an authentication password.
SNMPv3 Priv Auth-MD5: Add a user using SNMP v3 with authentication and
privacy. Click on the “Auth. Password” textbox and specify an authentication
password. Click on the “Privacy PassPhrase” textbox and specify a privacy
pass phrase.
SNMPv3 Priv Auth-SHA: Add a user using SNMP v3 with authentication and
privacy. Click on the “Auth. Password” textbox and specify an authentication
password. Click on the “Privacy PassPhrase” textbox and specify a privacy
pass phrase.
3. User Name: Click on the “User Name” textbox and specify a user name for
user using SNMP v3.
4. Access Mode: Click on the “Access Mode” drop-down menu from “Access
Mode” drop-down list to choose “Read Only” or “Read/Write”.
Read Only: Add a user using SNMP v3 with read-only access mode.
Read/Write: Add a user using SNMP v3 with read-write access mode.
5. Submit: Click “Submit” button after finishing SNMP V3 Setting.
