Page 12
3 Wire

Terminal 1  + ve Current Output (4 – 20mA SINK MODE)
    (NOT USED IN SOURCE MODE)
Terminal 2   - ve ground (4-20mA SINK MODE)
Terminal 3  - ve: Direct Current (DC) input (11-30VDC)
Terminal4  + ve: Direct Current (DC) input (11-30VDC)
Terminal 5  + ve Current Output (4 – 20mA SOURCE MODE)
Terminal   + ve: 0-10V output (P842 = 1) or 0-5V output (P842 = 0)
Terminal 7  - ve: 0-10V output (P842 = 1) or 0-5V output (P842 = 0)
Terminal 8   Relay 1 Normally Open (N/C) Contact (De-energised)
Terminal 9  Relay 1 Common
Terminal 10  Relay 1 Normally Closed (N/O) Contact (De-energised)
Terminal 11  Relay 2 Normally Open (N/C) Contact (De-energised)
Terminal 12  Relay 2 Common
Terminal 13  Relay 2 Normally Closed (N/O) Contact (De-energised)

Important Information
If the equipment is installed or used in a manner not specified in this
manual, then the protection provided by the equipment may be impaired.


Preparation for Operation
Before switching on, check the following:
  The IMP+
IMP+IMP+
IMP+ is mounted correctly.
  The power supply is correctly installed.
