Pulsar Imp 3 - Parameter Record

Page41
Parameter Record
APPLICATION (APP) MENU
Parameter Details Entered Values
No. Description Default 1 2 3 4 5
P100 Mode 1 = Dist.
P104 Measurement Units
Model
Dependant
P105 Empty Level
Model
Dependant
P106 Span
Model Dependant
P107 Near Blanking
Model Dependant
P108 Far Blanking 10.0%
RELAYS (rL) MENU
Parameter Details Entered Values
No. Description Default 1 2 3 4 5
P210 Relay 1 Type 0 = Not in Use
P211 Relay 1 Function 0 = Off
P213 Relay 1 On point 0.000
P214 Relay 1 Off point 0.000
Relay 2
Parameter Details Entered Values
No. Description Default 1 2 3 4 5
P220 Relay 2 Type 0 = Not in Use
P221 Relay 2 Function 0 = Off
P223 Relay 2 On point 0.000
P224 Relay 2 Off point 0.000
VOLUME (UoL) MENU
Parameter Details Entered Values
No. Description Default 1 2 3 4 5
P600 Vessel Shape 0
P601 Vessel Dimension 1 0.00
P602 Vessel Dimension 2 0.00
P603 Vessel Dimension 3 0.00
P604 Calculated Volume Read Only
P605 Volume Units
Model Dependant
P606 Correction Factor 1
P607 Max Volume Read Only
