Program Mode
This mode is used to set up the IMP+
IMP+IMP+
IMP+ or change information already set, this
is achieved by using the 4 push buttons located below the display.
Entering a value for each of the menu options that are relevant to your
application provides all the programming information.
Button Functions
There are 4 push buttons located under the display. Their name and
functions are as follows:
ESC Displays details of unit
Serial No. and Software
Version
Used to Navigate out of the
Menu System and return to
Run Mode. Also used to
Cancel a Parameter Value
entered in error.
UP
Displays Current
Temperature
Used for Navigating around
Menu Sytem and Increasing
Menu Option Values.
DOWN
Displays Current Echo
Strength (dB’s)
Used for Navigating around
Menu Sytem and Decreasing
Menu Option Values.
ENTER
Displays current mA output
Used to confirm an action such
as entering a Menu Option or
Enter a Parameter Value.
