Pulsar Imp 3 - Control Relay Setpoints; Control Relay ON;OFF Setpoints

Page29
P213 (Relay 1), P223 (Relay 2) - Relay “ON” Setpoint
This parameter determines the “ON” point for the control relay and should be
set as follows, in Measurement Units P104
Control Down Control Up
P213/P223 “ON” Setpoint P213/P223 “ON” Setpoint
Higher than Lower than
P214/P224 “OFF” Setpoint
P214/P224 “OFF” Setpoint
P214 (Relay 1), P224 (Relay 2) - Relay “OFF” Setpoint
This parameter determines the “OFF” point for the control relay and should be
set as follows, in Measurement Units P104
Control Down Control Up
P214/ P224 “OFF” Setpoint P214/ P224 “OFF” Setpoint
Lower than Higher than
P213/P223 “ON” Setpoint
P213/P223 “ON” Setpoint
