Using ERSC Add On Instructions (AOI) with RSLogix 5000
Publication ERSC-1521 Rev 1.0 – February 2019
You simply follow this same 5 step procedure for creating a new instance for any other modules you create using
the EDS file. For Ai2 modules created in PLC I/O mode, use the Ai2_PLCIO_419_5xx AOI. The drop down for the data
types for the Ai2_IN and Ai2_OUT parameters will automatically display only the Ai2 modules you have installed with
a PLC I/O connection.
