Black start function: If long press(>10sec) the start button 30s AFTER controller power on. The
“STATUS” lamp will become green which means black start function is enabled. and relay will
close and output for 10 min.
Dry Contact Terminal
Dry Contact Terminal: provided 2 input and 4 output dry contact signal.
Reset
Reset Button: Long press this button to restart the battery system.
ADD
ADD: 6 bit dial switches to manually distribute the communication address of the battery
system. Nether position is OFF, means “0”. Upper position is ON, means “1”. 1
st
bit to 5
th
bit is for
address, and the 6
th
bit dial switch support a 120Ω resistance.
CAN / RS485
CAN Communication Terminal: (RJ45 port) follow CAN protocol, for communication between
battery system and inverter.
RS485 Communication Terminal: (RJ45 port) follow Modbus RTU/TCP/IP protocol, for
communication between battery system and inverter.
RS232 Terminal
Console Communication Terminal: (RJ45 port) follow RS232 protocol, for manufacturer or
professional engineer to debug or service.
LAN Terminal
Console Communication Terminal: (RJ45 port) follow Modbus protocol, used for
communication between MBMS, switches or upper controller.
Link Port
Link Port Communication Terminal: (RJ45 port) follow RS485 protocol, for communication
between multiple serial battery modules and control module.
