Enforcer Programming Manual
Page: 52
Type Active Restore
0034 Lights When exit or entry timer starts
20 seconds after set/unset
procedure completed
0035 Follow Input When input triggers Dependent upon programming
0037 Restore 1 At code entry to set After 3 seconds
0038 Restore 2
At code entry to set When unset
Re-triggers whenever an additional area is set
0039 PIR Latch 1 When set (and in Walk Test) At alarm, or when unset
0040 PIR Latch 2 This is the inverse polarity to PIR Latch 1
0041 Mains Good Output showing the mains is healthy
0042 Detr Indn Enable
This output activates during walk test and also when a code is
entered to view indications – staying activated for the time for
which the indications are viewed.
0043 Follow Test New output for alternative bell test by activating SAB
0044 Off During Test New output for alternative bell test by activating SAB
0048 Detr Walk Test
This output is active during walk test, and will only deactivate
when all detectors have been tested.
0049
Detector Masked
(Not applicable on grade 2
systems)
If any detector goes into
‘mask’ condition the output will
trigger
When masking fault clears.
0050 Follow 24 Hour
If any input programmed as
“Day alarm” activates
When input restored
0051 Line Fault
When Line Fault signalled by
communicator
When fault clears
0052 Mains Fail
After pre-set time without
mains power
On restoration of mains
0053 Battery Faults
When battery disconnected or
load fail detected
At next valid code entry
0054 Low Volts At fault When fault clears
0055
Global Fault 1
(Faults: Modem, Battery,
Fuse, Line, Mains)
Activates if fault occurs only
when system is armed
When all faults cleared
0056
Global Fault 2
(Faults: as above)
Activates if fault occurs at any
time
When all faults cleared
0058 Guard Code Used When ‘guard’ code accepted After 60 seconds
0059 Engineer Access When entering Engineer Mode Leaving Engineer Mode
0060 Initialise Digi At power up Live for 45 seconds only
0063 Test ATE/GSM
Test signalling through PSTN
and GSM. Activates when a
test call is sent.(only used for
specific GSMs)
When test completed
0064
Test ATS
For use with ATE complying
with BSIA Form 175 to
initiate test call to ARC by
each available path.
Test signalling through PSTN
and GSM. Activates when a
test call is sent.
When test completed
0066 ATE not used
Makes the ATE pin 5V or 0V depending if ATE outputs are
inverted
0070-
0079
Fob Output 01-10
Can be used to triggers outputs via the keyfob. For example if an
output is programmed as type 0071 (Fob Output 02) and is wired
