Page: 7
3.4.2 The Internal Tag Reader (EUR-107)
The Internal tag reader can be used for setting/unsetting, entry control or access control. Refer
to page: 40 for installation details.
Tag Area (Where a valid tag must
be presented to set/unset)
Alert LED
Alarm LED
Tamper LED
Fault LED
Unset LED
3.4.3 The External Tag Reader (EUR-108)
The Internal tag reader can be used for setting/unsetting, entry control or access control. Refer
to page: 40 for installation details.
To set/unset the system using the External Tag Reader,
present a pre-programmed tag to the centre of the prox.
The prox will display the system status: Green = Unset.
Red = Set. Present the tag again within 10 seconds and
the system will set or unset.
The system will then set depending on the type of exit
mode programmed (Final door, Timed or Push to set)
3.5 Text Programming
Text may be programmed for input names, for the ‘sign-on’
message, and to identify the Set Level being set / unset. Each key is
allocated alpha-numeric and punctuation marks characters as shown
below:
The Enforcer 32-WE incorporates predictive text, so the system will
predict the word that is being spelt. For example, if ‘B’ is pressed,
and then and ‘e’ is pressed, Bedroom will be displayed, to accept
this press . If the word that is required doesn’t appear on the
LCD display, type the word as normal.
To type a word, press the relevant key the appropriate number of
times – e.g. for the letter ‘k’ press twice, or for the letter ‘s’
press four times.
For punctuation marks, press the key.
In addition, the keys are used as follows:
= make the character into a capital
= move cursor left
= clears cursor / adds a space
= moves cursor right
