Page #9 background image
Page: 9
4. The Engineer Menu
Any programming is only saved when exiting the Engineer menu. It is recommended that a Clean start is
performed after initial power up. See page: 33.
4.1 Software Revision
This option identifies the software version number, software serial number and product.
Software Revision Programming
1. Press or to scroll to 'SOFTWARE REVISION'.
Press .
2. The software revision will be displayed (e.g. V9.13)
Press orto return to the Engineer menu.
NOTE: The HUB software version is labelled on the PCB.
4.2 Choose Mode
If an Enforcer 32-WE I/O board or any Zone Expander Module (Input Expanders: ZEMs) are used, the
resistance, EOL mode and response time of the inputs can be programmed.
NOTE: Alarm 4K7, Tamper 2K2 must be selected if wiring double pole to an expander.
4.2.1 EOL Range (End of Line Range)
EOL Range programs the panel to operate with different resistor values
[0] Alarm: 1K, Tamper: 1K. [1] Alarm: 4K7, Tamper: 2K2.
[2] Alarm: 4K7, Tamper: 4K7. [2] Wide range.
4.2.2 EOL mode (Double End of Line (DEOL) or Single End of Line (SEOL))
EOL Mode programs all input expanders to operate as:
[0] Single End of Line (SEOL). [1] Double End of Line (DEOL).
4.2.3 Input Response Time
Input Response time programs the time that an input trigger must be present before the
Enforcer 32-WE system generates an alarm.
[01]-[30] = 100ms to 3000ms
NOTE: Settings below (<) 400ms do not comply with PD6662/EN50131.
Choose Mode Programming
1. Press or to scroll to 'CHOOSE MODE'. Press
.
2. Press [ or ] to select the 'EOL Range' for all wired
inputs
*
. Press .
3. Press [ or ] to select the 'EOL Mode' for all wired
inputs
*
. Press .
 Press [ or ] to select the 'Input Response
Mode' for all wired inputs
*
. Press to return to the
Engineer Menu.
*
On the I/O board and the expanders
SOFTWARE
REVISION?
Rev v09.13
0000ee02Enforcer
CHOOSE MODE?
EOL Range
4K7/2K2 [1]
EOL Mode
DR [1]
Input Response
100ms [01]
