Matrix 6/816 Installation Manual
RINS546-10 Page 23
Matrix 816
external
ombined
sounder
BELLE
с
Transistor output
PGM 2, PGM 3 and PGM 4
PGM
10К
4К7
Relay output
PGM 1
С1 NO1 NC1
PGM output stage diagram
Contacts position when output is off
relay coil is de-energized()
NOTE: PGM1 must be programmed as “External Bell”. PGM 2 (in this example) must be
programmed as “Follow Strobe”.
