Matrix 6/816 Installation Manual
RINS546-10 Page 31
4. SPECIFICATIONS
4.1.1 Matrix 6
ZONES
POWER SUPPLY
Number of programmable zones – 6 Power input – 17V AC
Zone loop types – Normally Open, Normally Closed, Low voltage output
–
13.8V DC regulated
SEOL, DEOL Max. capacity power output (incl. panel)
–
1.25A
Zone loop current – 0.5mA max. Max. power for ext. devices (excl. battery)
–
0.6A
Zone loop timers – 0.3sec. (normal zones),
30 ms (Fast Zones)
TRANSFORMER REQUIRED
Zone wire resistance – not more than 470Ohm For 230VAC, Primary – 230VAC, 50Hz, 20W min.
PGM OUTPUTS
Secondary – 17VAC, 1.25A
Number of programmable outputs – 4 For 120VAC, Primary – 120VAC, 50Hz, 50W min.
Output types – up to 36 Secondary – 16.5VAC, 40VA
PGM1 – Relay Contacts, 30V DC @ 3A
PGM2 – Transistor Open Collector, 200mA
CURRENT CONSUMPTION
PGM3 – Transistor Open Collector, 200mA Matrix 6 PCB (alone) – 60mA
PGM4 – Transistor Open Collector, 500mA Remote keypad MX-ICON – 50mA
Remote keypad MX-LED – 60mA
DIGITAL COMMUNICATOR
BATTERY
Digital communicator
–
Analogue line Type – Lead Acid rechargeable
Lightning protection – 6.75kV/125Amps Battery Charge commencing
– min. 5.5V
Battery Capacity
–
2.8A/h … 7.2A/h
MECHANICAL
Protection on BAT terminals – short & reverse
Dimension – 340 х 280 х 101mm
Material & colour – Metal / White Polymer
FUSE CONTROL
AC input – 2A (quick blow F1L)
ENVIROMENTAL
Auxiliary supply output
–
1A (quick blow F1L)
Operation temperature: 0 to +40
C
RKP supply output
–
1A (quick blow F1L)
Storage temperature: –20 to +40
C
Battery Input – 5A (slow blow T5H)
When all parts are working normally, this equipment in combination with the PSTN and suitable ARC
equipment will meet the requirements of ATS2.
This product is suitable for use in systems designed to comply with
PD6662:2010 at Security Grade 2 and Environmental Class 2.
