Matrix 6/816 Installation Manual
RINS546-10 Page 3
Example 1
NOT
ACCEPTABLE
50m. 100m.
K+
KD
K-
Keypad 1
(1 KEN)
Keypad 3
(1 KEN)
Keypad 4
(1 KEN)
Keypad 2
(1 KEN)
Example 2
AUX+ / K+
KD
AUX- / K-
Keypad 1
(1 KEN)
Keypad 3
(1 KEN)
50m. 100m.
ACCEPTABLE
SOLUTION
Keypad 2
(1 KEN)
Keypad 4
(1 KEN)
