LCD Keypad Interpretation Event Log Table
FG Press E Description
Entry Top Line Bottom Line
Entry Exit Zone number Entry / Exit timer expired. The number refers to the zone.
Personal Attack Zone number PA zone activated, number signifies zone (00 = keypad)
Fire Alarm Zone number FIRE zone activated, number signifies zone (00 = keypad)
Alarm Zone number Zone name Burglary on zone, number signifies zone
Zone Tamper Zone number Zone name Tamper on zone, number signifies zone
Medical Alarm Zone number Medical alarm, number signifies zone (00 = keypad)
Tamper 01 Global tamper loop broken
Tamper 02 Bell tamper loop broken
Tamper 04 Plug on zone expander board not present
Tamper 06 Remote device missing caused tamper
Tamper 08 Keypress tamper
Tamper 09 Remote device tamper
Line Fail Alarm Telephone line fail alarm
Omit Zone 01-32 Zone name Zone omitted, number signifies zone
Device Tamper
Device type
01-99
Device type Remote device Auxiliary tamper
PA Restore Zone number User name Personal Attack restore
Zone restore Zone number User name Zone restore
Fire restore Zone number User name Fire restore
GT restore Zone number User name Global tamper restore
Medical restore Zone number User name Medical restore
Key Box Open Zone Name Zone number A key box zone was opened
Key Box Close Zone Name Zone number A key box zone was closed
Up/Downloading Events
Panel ans tel. Panel answered the telephone
Panel hung tel. Panel hung up the telephone line
Full upload Full data to panel
Full download Full data from panel
Partial upload Partial data to panel
Upload
complete
Data to panel complete
Download Data from panel complete
Bad UDL code Incorrect UDL code
UDL code OK UDL code accepted
Time + Date User name Time/Date changed by PC
LCD expected Local connection expected
PC arm/disarm PC armed / disarmed the panel
Open / Close
Armed 01-32 A User name Armed in mode A by user, number signifies code used
Armed 01-32 B User name Armed in mode B by user, number signifies code used
Armed 01-32 C User name Armed in mode C by user, number signifies code used
Armed 01-32 D User name Armed in mode D by user, number signifies code used
Disarmed 01-32 User name Disarmed by user, number signifies code number used
Inactivity Arm 01-32 Armed due to inactivity timer
Arm Depend Armed due to dependency on other partitions
Disarm depend 01-32 Disarmed due to dependency on other partitions
UC after alarm 01-32 User name User code after alarm, number signifies user
Bell time end Bell time expired
Power on Panel powered up
