Pyronix Matrix Series User Manual

! Matrix 832 / 832+ / 424
RINS428-5 Page 149
12.12 Programmable Outputs Connections
12.12.1 Belle Connection to Matrix 832
NVM Reset
Relay
17V~ +BAT- B+ B- BT GT NC C NO1/ PG M1 PG M2 PG M3 PG M4 KD Z1 Z2 Z3 Z4 COM COM +AUX- Z5 Z6 Z7 Z8 COM COM RING
TIP R-1 T-1
B-
B+
BA
STB
SPARE
BT
TF
BEL LE
IMPORTANT
The Belle may be connected / programmed using different
programmable outputs.
In this instance PGM1 is programmed as “External Bell”
and PGM2 is programmed as “Strobe” - See section 4.11
PGM 1 = BA = BELL OUTPUT
PGM 2 = STB = STROBE TRIGGER
1
7
V
A
C
O
u
t
p
u
t
+
-
B
A
T
B- B+ BA STB BT TF TAMPER
SPARE
+BAT-
