Pyronix Matrix Series - Section 1: Technical Specifications & System Overview; Technical Specifications; Main Control Panel

! Matrix 832 / 832+ / 424
RINS428-5 Page 1
Section 1: Technical Specifications & System Overview
1.1 Technical Specifications
1.1.1 Main Control Panel
Matrix 832+ Matrix 832 Matrix 424
ZONES
Zone Loop Current
0.54mA - Max 0.54mA - Max 0.54mA - Max
Zone Activation Resistance
DEOL
Short circuit
<800Ω <800Ω <800Ω
Normal
>800Ω to <6kΩ >800Ω to <6kΩ >800Ω to <6kΩ
Activated
>6kΩ to <36kΩ >6kΩ to <36kΩ >6kΩ to <36kΩ
Open circuit
>36kΩ >36kΩ >36kΩ
Normally Closed
Normal
<4kΩ <4kΩ <4kΩ
Activated
>4kΩ >4kΩ >4kΩ
Doubled
Both zones Normal
>2kΩ to <6kΩ >2kΩ to <6kΩ >2kΩ to <6kΩ
Both zones Activated
>11kΩ to <35kΩ >11kΩ to <35kΩ >11kΩ to <35kΩ
Zone n Activated
>8kΩ to <11kΩ >8kΩ to <11kΩ >8kΩ to <11kΩ
Zone n+16 Activated
>6kΩ to <8kΩ >6kΩ to <8kΩ >6kΩ to <8kΩ
Zone Doubled: Tamper
Activated
<2kΩ or >35kΩ <2kΩ or >35kΩ <2kΩ or >35kΩ
Zone Response Time
Standard Zones
350ms 350ms 350ms
Fast Zones
100 ms 100 ms 100 ms
Only Zone 1 Fast
Zone1 - 30ms
Other zones - 350ms
Zone1 - 30ms
Other zones - 350ms
Zone1 - 30ms
Other zones - 350ms
Zone Protection
18V Varister 18V Varister N/A
PROGRAMMABLE OUTPUTS (PGM)
PGM 1
Relay contacts
30V@3A
Relay contacts
30V@3A
Relay contacts
30V@3A
PGM 2
Relay contacts
30V@3A
Open Collector
12V@200mA
Open Collector
12V@200mA
PGM 3
Open Collector
12V@200mA
Open Collector
12V@ 200mA
Open Collector
12V@200mA
PGM 4
Open Collector
12V@10mA
Open Collector
12V@10mA
Open Collector
12V@10mA
DIGITAL COMMUNICATOR
Telephone Line Monitoring
Yes Yes Yes
Digital Communicator
Analogue Line Analogue Line Analogue Line
Lightning Protection
Heavy duty protection
6.75kV / 125A
Heavy duty protection
6.75kV / 125A
Heavy duty protection
6.75kV / 125A
POWER SUPPLY
Power Input
17Vac 17Vac 17Vac
Transformer Rating
44VA (Metal case)
21VA (Plastic case)
21VA 21VA
EN50131-6 Type
A A A
Voltage Output
13.6Vdc@1A regulated
Max 13.8V Min 10.5V
13.6Vdc@1A regulated
Max 13.8V Min 10.5V
13.6Vdc@1A regulated
Max 13.8V Min 10.5V
Ripple
1% Max. 1% Max 1% Max
Total Current Output
AUX, Bell, K+
600mA (Plastic)
1.1A (Metal)
600mA 600mA
Panel Current Requirement
200mA 200mA 200mA
