Pyronix Matrix Series User Manual

Matrix 832 / 832+ / 424
Page 26 RINS428-5
Zone Types Default Notes
1 Zones Normally Closed
2 Zone Doubling Disabled
3 Fast Zones Disabled
4 Zone 1 Fast Zone Disabled
Zone Attributes Default Notes
1 Chime Disabled
2 Test Disabled
3 Mask Disabled
4 Double Knock Disabled
5 Normally Open Disabled
7.4.3 Zone Types, Zone Attributes & Zone Settings
Zone Settings
Zone Arm A Arm B Arm C Arm D Attribute Partition
Z01
Entry/Exit Entry/Exit Entry/Exit Entry/Exit Off 1
Z02
Immediate Immediate Immediate Immediate Off 1
Z03
Immediate Immediate Immediate Immediate Off 1
Z04
Immediate Immediate Immediate Immediate Off 1
Z05
Immediate Immediate Immediate Immediate Off 1
Z06
Immediate Immediate Immediate Immediate Off 1
Z07
Immediate Immediate Immediate Immediate Off 1
Z08
Tamper Tamper Tamper Tamper Off 1
Z09
Immediate Immediate Immediate Immediate Off 1
Z10
Immediate Immediate Immediate Immediate Off 1
Z11
Immediate Immediate Immediate Immediate Off 1
Z12
Immediate Immediate Immediate Immediate Off 1
Z13
Immediate Immediate Immediate Immediate Off 1
Z14
Immediate Immediate Immediate Immediate Off 1
Z15
Immediate Immediate Immediate Immediate Off 1
Z16
Immediate Immediate Immediate Immediate Off 1
Z17
Immediate Immediate Immediate Immediate Off 1
Z18
Immediate Immediate Immediate Immediate Off 1
Z19
Immediate Immediate Immediate Immediate Off 1
Z20
Immediate Immediate Immediate Immediate Off 1
Z21
Immediate Immediate Immediate Immediate Off 1
Z22
Immediate Immediate Immediate Immediate Off 1
Z23
Immediate Immediate Immediate Immediate Off 1
Z24
Immediate Immediate Immediate Immediate Off 1
Z25
Immediate Immediate Immediate Immediate Off 1
Z26
Immediate Immediate Immediate Immediate Off 1
Z27
Immediate Immediate Immediate Immediate Off 1
Z28
Immediate Immediate Immediate Immediate Off 1
Z29
Immediate Immediate Immediate Immediate Off 1
Z30
Immediate Immediate Immediate Immediate Off 1
Z31
Immediate Immediate Immediate Immediate Off 1
Z32
Immediate Immediate Immediate Immediate Off 1
