ABOUT YOUR SYSTEM INTRODUCTION
1-2
Specifications
Table 1.1: System Specifications
SPECIFICATIONS DESCRIPTION
Form factor 1U rack mount
Dimensions (W x H x D)
17.6 x 1.7 x 35.0 inches
448.2 x 43.2 x 890.1 mm
Processor
Processor type:
Intel® Xeon® processor E5-2600 v3 product family
Max. TDP support: 135W
Number of processors: 2
Internal Interconnect: 6.4 / 8.0 / 9.6 GT/s
L3 cache: Up to 45 MB
Chipset
Intel
® C610
Memory
Total slots: 16
Capacity: up to 512 GB RDIMM / up to 1024 GB LRDIMM
Memory type: 2133 MHz DDR4 RDIMM/LRDIMM
Memory size: 32 GB, 16 GB, 8 GB RDIMM / 64 GB, 32 GB LRDIMM
Storage controller
Onboard (Intel® C610):
10x SATA 6Gb/s ports
SATA RAID 0, 1, 10
Optional controller:
Quanta LSI® 2208 6Gb/s SAS mezzanine
Quanta LSI® 3108 12Gb/s SAS mezzanine
Networking
LOM:
One Intel® I350 dual-port 1 GbE
Dedicated 10/100/1000 management port
Optional NIC:
Quanta Intel® 82599 dual-port 10G OCP mezzanine
Expansion slot One x16 PCIe G3 slot
Storage 12 x 3.5" or 2.5" fixed SATA/SAS HDD/SSD
Video Integrated AST2400 with 8MB DDR3 video memory (optional)
Front I/O
LEDs: LAN/Power/HDD array/Status/ID
Buttons: ID/Power
Rear I/O
2x USB 3.0 ports
1x VGA port
1x RS232 serial port
2x GbE RJ45 ports
1x 10/100/1000 RJ45 management port
TPM Yes (option)
