INSTALLING HARDWARE INSTALLING THE PROCESSOR
2-22
6. Lift the load plate upright.
Figure 2-22. Lifting Processor Load Plate
7. Remove the processor.
Figure 2-23. Removing the processor
8. To remove the second processor, repeat the previous steps.
Installing the Processor
1. Push the locking lever down and in to unlock the load plate.
2. Push the release lever down and out to release the load plate.
3. Lift the load plate upright.
4. If there is a processor dust cover, remove it at this time.
5. Remove the new processor from its packaging. Make sure to hold the processor by
the sides. Do NOT touch the underside of the processor.
AVOID CONTACT WITH ANY THERMAL GREASE ON THE PROCESSOR.
