INSTALLING HARDWARE TOP COVER
2-11
2.5 Top Cover
Removing the Top Cover
The following procedure illustrates the system.
1. Press the top cover release button (A).
2. Slide the top cover away from the HDDs. (B)
Figure 2-11. Removing the Top Cover
Installing the Top Cover
1. Place the top cover on the chassis (A).
CAUTION!
ENSURE ALL POWER IS DISCONNECTED FROM THE SYSTEM BEFORE PROCEEDING.
!
B
A
