No. Component No. Component
1 PCIe low-profile covers 8 Ethernet Port 2 (GbE RJ45)
2 Battery backup unit 9 Power button
3 Power supply unit 10 Service port
Note
This port is only for engineering
purposes.
4 Reset button 11 Ethernet port 4 (10GbE SFP+)
5 USB 3.0 Type-A ports
Note
This port is only for engineering
purposes.
12 Ethernet port 5 (10GbE SFP+)
6 Ethernet port 1 (GbE RJ45, management
port)
13 Ethernet port 7 (10GbE SFP+)
7 Ethernet port 3 (GbE RJ45) 14 Ethernet port 6 (10GbE SFP+)
ES2486dc User Guide
Product Overview 14
