QOLSYS Panel 2+ - HARDWARE SPECIFICATIONS

SPECIFICATIONS
Items
Parameters
IQ Panel 2
LED Indicator
Status LED
Green (Disarmed), Red (Armed). Note: not enabled for EN50131 certified systems
Speaker
Stereo 1W x 2
Stereo speakers (unified audio)
Camera
Front Camera
5MP fixed focus
Microphone
Microphone
Stereo microphones x 2
Siren
Piezo
SPL minimum 85dB. Type Z as per EN50131-4: internal, self-powered
Tamper
Tamper Switch
Reporting tamper release button
Battery
Type
3.8v Lithium Polymer 1715 mAh. Low battery threshold: 3.5V and 10% indication for battery capacity
Buttons
Standby
Right side button used for sleep/wake, hard reboot, and clean screen cancel
Mechanical
Dimension
5”H x 7.75”W x .75”D (195mm x 130mm x 23mm)
Mechanical
Weight
0.4 kg
Power Supply
AC/DC External Plug-in
Adapter
Output: 7vDC 1A, Input 230VAC -10%/+15% /0.7A/50Hz (for CE/EN Certified Systems). Current
consumption during set & unset procedure: 340mA; quiescent current: 125mA; max current in alarm
mode: 1078mA. Control Panel and power supply are suitable for installation only within the protected
premises.
Standby Time
12 h. (Battery recharge time (up to 80% of capacity): 72 h. Energy level of battery in its charged state is
100%.)
Mount
Back Plate
Wall mount or table top (stand included). For EN50131 certified systems only wall mount is allowed.
Environment
Altitude: Min 0 m to Max 2000m
Humidity range: 20% RH to 93% RH (non-condensing)
Operating Ambient Temperature: Min -10°C to Max 40°C
Storage Ambient Temperature: in -10°C to Max 55°C
EN50130-5 Class I - Indoor ordinary location
