QOLSYS Panel 2+ - PANEL MOTION SETTINGS

SECURITY SENSORS
Panel Motion Settings
Control settings for the built-in Panel Motion Detector. Change the sensitivity
threshold and mask off up to 4 customizable areas to prevent false triggers.
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 83 173
SECURITY SENSORS
FIND IT
PANEL MOTION SETTINGS*
Swipe down
for access
INSTALLATION
SETTINGS
ADVANCED SETTINGS
ENTER CODE (1111, 2222)
DEVICES
Masking:
Touching “ADD MASK” will give a drawable
area (green) that is not taken in to account
for motion pixelation change, then touch
“SAVE MASK” to save. Up to 4
independent mask areas can be drawn.
PANEL MOTION SETTINGS
Sensitivity Setting:
Touch “SETTING” to change the the Panel
Motion sensitivity between Low (default),
Medium and High. Use the Green to Red
bar on the right side of the screen to
determine trigger threshold.
* Not evaluated for use with EN Grade 2
applications.
