QOLSYS Panel 2+ - INTERIOR COMPONENTS

PANEL OVERVIEW
INTERIOR
Panel Battery*
Z-Wave Plus™
Radio
LTE Sim Card
“Tool-less”
Terminal Block
(Not approved for CE or EN Grade 2)
Tamper Switch
Cellular Antenna
The battery should NEVER be disconnected without following proper power-down procedures
Failure to comply may result in data corruption, panel failure, and a void of the manufacturer's warranty
*CAUTION
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 7 173
Siren
Security
RF Radio
(Not provided for CE or EN Grade 2)
Barrel Jack
Power
PowerG Antenna
PowerG Radio
(PowerG Radio is Standard on IQ
Panel 2 PowerG modem is required
for EN Grade 2 compliant installations)
