Please note: When using the PG8905 with Group 51, the High & Low threshold settings are set to 4°C and 38°C by
default. When using Group 52, the Low threshold setting is set to 4°C by default. When using Group 53, the High
threshold setting is set to 38°C by default. Thresholds can be customized between -40°C and 85°C.
SENSOR GROUPS
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 73 173
TEMPERATURE
GROUP
NAME
SUPERVISED
SCENARIO
51
Temp Non Reporting
Y
Only for use with the PowerG Temp Sensor (PG8905). This sensor
group does not report to the Central Station. Allows for actual
temperature monitoring (thermometer) with customizable high/
low threshold settings
52
Freeze
Y
Triggers an alarm when sensor detects low temperatures.
NOTE: temperature sensor functionality has not been evaluated by CE/EN Grade 2.
53
Temp Reporting
Y
Triggers an alarm when sensor detects high temperatures.
NOTE: temperature sensor functionality has not been evaluated by CE/EN Grade 2.
