5 Select document size. If you change default dimensions, size will change to
Custom.
6 Enter the Address position and Paper type (standard or glossy). If the
document is pre-folded, enter the number of leaves it folds into.
7 Enter the paper weight and the document thickness and weight will
automatically calculate, or press Computed and enter actual gures.
8 If using barcode or OMR marked documents, enter the denition name. Press
Region of Interest to specify label position.
9 Enter the location of the label and press OK.
10 if Doc Id mode is to be used, select On. This reads a label character and
compares its string value with the string entered in Doc Id. This conrms that the
correct document type is used.
11 The shield setting controls the amount of shielding over the separator rollers,
and should not normally require adjustment. However, if stream-feeding or erratic
double feeds occur, try moving the shield back (ie. reducing the percentage). If
documents are not properly picking up, move it forward.
12 Press Save when done.
The document is now fully dened and is available for use.
Documents can also be created from the Menu screen if you
have appropriate access rights.
