SECTION 8 – UNIT OPERATION
8
REMOTE BAS/EMS TEMPERATURE RESET
USING A VOLTAGE OR CURRENT SIGNAL
The Remote Reset Option allows the Control Center
of the unit to reset the chilled liquid setpoint using a
0 to 10VDC input, or a 4 mA to 20 mA input connected
to XTBC1 Terminals A- and A+. Whenever a reset is
called for, the change may be noted by pressing the
COOLING SETPOINTS key twice. The new value
will be displayed as “REM SETP = XXX°F.”
If a 0 VDC to 10 VDC signal is supplied, it is applied
to Terminals A+ and A-, and jumper JP1 on the I/O
board must be inserted between pins 2 and 3. To calcu-
late the reset chilled liquid setpoint for values between
0 VDC and 10 VDC use the following formula:
Setpoint = Local Chilled Liquid Setpoint + °Reset
°Reset = (DC voltage signal) x (*Max Reset Value)
10
Example:
Local Chilled Liquid Setpoint = 45°F (7.22°C)
*Max Reset Value = 20°F (11.11°C)
Input Signal = 6 VDC
(English)
°Reset = 6 VDC x 20°F
10
New Setpoint = 45°F + 12°F = 57°F
(Metric)
°Reset = 6 VDC x 11. 11°C
10
New Setpoint = 7.22°C + 6.67°C = 13.89°C
* Max Reset Value is the “Max EMS-PWM Remote Temp. Reset”
setpoint value described in Remote Setpoint Control on page
129 under “Cooling Setpoints”. Programmable values are from
2°F to 40°F (1.11°C to 11.11°C).
= 12°F Reset
= 6.67°C Reset
If a 4 mA to 20 mA signal is supplied, it is applied to
Terminals A+ and A- and jumper JP1 on the I/O board
must be installed between pin 1 and 2. To calculate the
chilled liquid setpoint for values between 4 mA and 20
mA use the following formula:
Setpoint = Local Chilled Liquid Setpoint + °Reset
°Reset = (mA signal - 4) x (*Max Reset Value)
16
Example:
Local Chilled Liquid Setpoint = 45° (7.22 °C)
*Max Reset Value = 10 °F (5.56 °C)
Input Signal = 12 mA
(English)
°Reset = 8 mA x 10°F
16
Setpoint = 45 °F + 5 °F = 50 °F
(Metric)
°Reset = 8 mA x 5.56°C
16
Setpoint = 7.22°C + 2.78°C = 10.0°C
= 5°F Reset
= 2.78°C Reset
A 240 to 24 Volt Ratio Transformer (T3) is
used to derive nominal 12 V output from
the 120 V supply.
