SECTION 2 – PRODUCT DESCRIPTION

FIGURE 5 - POWER PANEL / CONTROL COMPONENTS

ITEM DESCRIPTION

1 Fan Contactor

2 Fan Fuses

3 Control Relay

4 Microcomputer Control Center

5 Display

6 Keypad

7 XTBC1

8 Microboard

9 XTCB2

10 XTBF2

11 Compressor Contactors

12 Compressor Overloads

LD13248
