OPERATIONAL LIMITATIONS (ENGLISH)
SECTION 5 – TECHNICAL DATA
TABLE 4 - TEMPERATURES AND FLOWS
UNIT
DESIGNATION
TEMPERATURE
WATER FLOW
(GPM) MIN
WATER FLOW
(GPM) MAX
AIR ON CONDENSER (°F)
MIN
1
MAX
2
MIN
3
MAX
4
STANDARD EFFICIENCY
QTC3070TSE 40 55 60 285 -10 125
QTC3075TSE 40 55 100 355 -10 125
QTC3085TSE 40 55 100 385 -10 125
QTC3095TSE 40 55 100 385 -10 125
QTC3110TSE 40 55 150 625 -10 125
QTC3125TSE 40 55 100 385 -10 125
QTC3140TSE 40 55 150 625 -10 125
QTC3160TSE 40 55 150 625 -10 125
HIGH EFFICIENCY
QTC3040THE 40 55 41 224 -10 125
QTC3050THE 40 55 48 224 -10 125
QTC3055THE 40 55 60 285 -10 125
QTC3060THE 40 55 60 285 -10 125
QTC3080THE 40 55 150 625 -10 125
QTC3090THE 40 55 100 385 -10 125
QTC3100THE 40 55 100 385 -10 125
QTC3120THE 40 55 100 385 -10 125
QTC3130THE 40 55 150 625 -10 125
QTC3150THE 40 55 150 625 -10 125
QTC3170THE 40 55 150 625 -10 125
QTC3205THE 40 55 230 625 -10 125
QTC3225THE 40 55 230 650 -10 125
NOTES:
1. For leaving liquid temperature below 40°F (4°C) (to 10°F [-12°C]) optional low temperature glycol kit required. Contact your
nearest Quantech O󰀩ce for application requirements.
2. For leaving liquid temperature higher than 55°F (13°C), contact the nearest Quantech O󰀩ce for application guidelines.
3. The evaporator is protected against freezing to -20°F (-29°C) with an electric heater as standard.
4. For operation at temperatures below 30°F (-1°C), install the optional Low Ambient Kit on the system.
5. For operation at temperatures below 0°F (-18°C), install the optional Low Ambient Kit with Variable Speed Fans on the system.
Excessive ow will cause damage to the
cooler. Do not exceed maximum cooler
ow. Special care should be taken when
multiple chillers are fed by a single pump.
