QUANTECH
24
FORM QTC3-NM1
ISSUE DATE 08/03/2022
SECTION 2 – PRODUCT DESCRIPTION
PRODUCT IDENTIFICATION NUMBER (PIN)
TABLE 2 - COMPLETE PIN NUMBER DESCRIPTION
FEATURE
FEATURE
DESCRIPTION
OPTION OPTION DESCRIPTION
MODEL Model (PIN 1-4) QTC3
CAPACITY
Capacity
(PIN 5-8)
055T 055T
060T 060T
070T 070T
075T 075T
080T 080T
085T 085T
090T 090T
095T 095T
100T 100T
110T 110T
120T 120T
125T 125T
130T 130T
140T 140T
150T 150T
160T 160T
170T 170T
205T 205T
225T 225T
UNIT
Unit Designator
(PIN 9)
S Standard E󰀩ciency
H High E󰀩ciency
REF. Refrigerant (PIN 10) E R-410A
VOLTS
Voltage
(PIN 11 & 12)
17 200/3/60
28 230/3/60
40 380/3/60
46 460/3/60
50 380-415/3/50
58 575/3/60
STARTER
Starter
(PIN 13)
X Across the Line starter
T Soft Start
DESIGN
Design Series
(PIN 14)
A Design Series A (MicroChannel) Copeland Compressor
C
Design Series C (MicroChannel CE/ETL Panel) Copeland Com-
pressor
D Design Series D (MicroChannel) Bitzer Compressor
F Design Series F (MicroChannel CE/ETL Panel) Bitzer Compressor
DEV
Development Level
(PIN 15)
B Development Level B
POWER
Power Field
(PIN 16 &17)
SX SP Supply TB
SD SP NF Disconnect Switch
BC SP Circuit Breaker w/ Lockable Handle, 65kA SCWR
BX SP Circuit Breaker w/ Lockable Handle
MB MP Supply w/Ind Sys CB&L Ext Handles
TRANS
Cntrl Transformer
(PIN 18)
X No Control Transformer Required
T Control Transformer Required
Q Special Control Transformer Required
