Quantech QTC3150THE User Manual

51
QUANTECH
FORM QTC3-NM1
ISSUE DATE 08/03/2022
SECTION 5 – TECHNICAL DATA
55
TABLE 9 - PUMP ELECTRICAL DATA (60 HZ)
PUMP
MODEL
HORSE
POWER
RPM
PUMP ELECTRICAL DATA
208-3-60 HZ 230-3-60 HZ 380-3-60 HZ 460-3-60 HZ 575-3-60 HZ
FLA LRA FLA LRA FLA LRA FLA LRA FLA LRA
A 5 3600 12.0 92.0 7.1 55.5 6.0 46.0 4.8 36.8
B 7.5 3600 17.6 126.0 10.6 78.0 8.8 63.0 7.0 50.4
C 10 3600 23.6 162.0 14.3 102.0 14.0 81.0 9.4 64.8
D 15 3600 35.0 232.0 20.9 143.0 17.5 116.0 14.0 92.8
E 5 1800 13.0 92.0 7.9 55.5 6.5 46.0 5.2 36.8
F 15 3600 35.0 232.0 20.9 143.0 17.5 116.0 14.0 92.8
G 7.5 3600 17.6 126.0 10.6 78.0 8.8 63.0 7.0 50.4
H 10 3600 23.6 162.0 14.3 102.0 14.0 81.0 9.4 64.8
I 15 3600 35.0 232.0 20.9 143.0 17.5 116.0 14.0 92.8
J 5 1800 13.0 92.0 7.9 55.5 6.5 46.0 5.2 36.8
K 15 3600 35.0 232.0 20.9 143.0 17.5 116.0 14.0 92.8
L 20 3600 45.0 290.0 28.7 190.0 22.5 145.0 18.0 116.0
M 3 1800 8.0 64.0 4.7 38.0 4.0 32.0 3.2 25.6
N 7.5 3600 17.6 126.0 10.6 78.0 8.8 63.0 7.0 50.4
O 10 3600 23.6 162.0 14.3 102.0 14.0 81.0 9.4 64.8
P 15 3600 35.0 232.0 20.9 143.0 17.5 116.0 14.0 92.8
R 5 1800 13.0 92.0 7.9 55.5 6.5 46.0 5.2 36.8
S 10 1800 24.0 162.0 15.1 102.0 12.0 81.0 9.6 64.8
T 15 1800 36.4 232.0 22.0 143.0 18.2 116.0 14.6 92.8
U 7.5 1800 18.4 126.0 11.1 78.0 9.2 63.0 7.4 50.4
V 20 3600 45.0 290.0 28.7 190.0 22.5 145.0 18.0 116.0
NOTES:
Reference PIN 59 for Pump Model.
Use this table along with Table 11 - Electrical Data Without Pumps on page 52 to determine electrical data of the unit plus the pump.
TABLE 10 - TRANSFORMER LOAD
VA
VOLT 2000 3000
208 9.6 14.4
230 8.7 13.0
380 5.3 7.9
460 4.3 6.5
575 3.5 5.2
