Quantech QTC3150THE User Manual

47
QUANTECH
FORM QTC3-NM1
ISSUE DATE 08/03/2022
SECTION 5 – TECHNICAL DATA
55
REFRIGERANT R-410A
QTC3
STANDARD EFFICIENCY UNITS
070TSE 075TSE 085TSE 095TSE 110TSE 125TSE 140TSE 160TSE
NOMINAL RATINGS
**
TONS 71.0
77.8 81.8 95.6 118.1
126.1 143.0
167.4
KW INPUT 77.5 86.3 93.0 111.5 134.6 142.6 165.0 192.1
EER 10.4 10.0 9.8 9.7 9.8 9.7 9.7 9.7
IPLV 16.1
15.6 15.8 14.5 15.0
15.8 15.8
15.6
GENERAL UNIT DATA
Length
116.1 116.1 116.1 142.7 142.7 187.7 187.7 232.7
Width 88.0 88.0 88.0 88.0 88.0 88.0 88.0 88.0
Height 94.2 94.2 94.2 94.2 94.0 94.2 94.2 94.2
Number Of Refrigerant Circuits
2 2 2 2 2 2 2 2
REFRIGERANT CHARGE, OPERATING
R-410A, CKT1/CKT2, lb
43/43 47/44 57/57 55/58 54/62 75/71 75/70 90/87
Oil Charge, CKT1/CKT2, gal 2.58/2.58 3.28/2.58 3.28/2.76 3.28/3.33 3.33/3.33 4.99/2.76 4.99/3.33 4.99/4.99
Shipping Weight 3578 3898 4168 4791 5183 6148 6414 7734
Operating Weight
3623 3954 4241 4864 5293 6232 6524 7818
COMPRESSORS, SCROLL TYPE
Compressors Per Circuit
3/3 3/3 3/3 3/2 2/2 3/3 3/2 3/3
Compressors Per Unit
6 6 6 5 4 6 5 6
NOMINAL TONS PER COMPRESSOR
Circuit 1
13 15 15 15 32 32 32 32
Circuit 2
13 13 15 32 32 15 32 32
CONDENSER
Total Face Area Ft
2
106.9 106.9 106.9 133.6 160.3 213.8 213.8 267.2
Number Of Rows 1 1 1 1 1 1 1 1
Fins Per Inch
20 20 20 20 20 20 20 20
CONDENSER FANS, LOW SOUND
Number Of Fans, CKT 1/CKT 2
2/2 2/2 2/2 3/2 3/3 4/4 4/4 5/5
Fan, hp 2 2 2 2 2 2 2 2
Fan, rpm 1160 1160 1160 1160 1160 1160 1160 1160
Total Chiller, cfm
60000 60000 60000 75000 93600 120000 120000 150000
EVAPORATOR
Water Volume, gal
5.4 6.7 8.8 8.8 13.2 10.0 13.2 10.0
Maximum Water Side Pressure,
psig
150 150 150 150 150 150 150 150
Maximum Refrigerant Side
Pressure, psig
450 450 450 450 450 450 450 450
Minimum Chiller Water Flow
Rate, gpm
60 100 100 100 150 150 150 150
Maximum Chiller Water Flow
Rate, gpm
285 355 385 385 625 625 625 625
Water Connections Size, in.
3 3 3 3 3 4* 4* 4*
* Side extension kit (standard), evaporator nozzle remains 3 in.
** Rated in accordance with AHRI Standard 550/590 at an air on condenser temperature of 95°F and a leaving chilled water temperature of 44°F.
NOTE: Additional rating information can be provided by your local Quantech technical support.
PHYSICAL DATA QTC3040T – QTC3225T 60 HZ
TABLE 6 - PHYSICAL DATA (ENGLISH) 60 HZ
