SECTION 2 – PRODUCT DESCRIPTION
FEATURE
FEATURE
DESCRIPTION
OPTION OPTION DESCRIPTION
OVERLOAD PIN 35
X X
Q Special Quote
PIN36 PIN 36
K Quick Start
Q Special Quote
HTR
Crankcase Heater
(Pin 37)
H Crankcase Heater Standard
Q Special Crankcase Heater required
DWP
DWP
(PIN 38)
X 150 psig DWP Waterside
3 300 psig DWP Waterside
INS
Insulation
(PIN 39)
X Standard Insulation
D Double Thick Insulation
Q Special Insulation required
FLANGES
Flanges
(PIN 40)
X No Flanges required
V Grooved Flanges required
Q Special Flanges required
FLOW
Flow Switch
(PIN 41)
X No Flow Switch required
S One Flow Switch Required
Y Flow Switch With Extension Kit
VESSEL
Vessel Codes
(PIN 42)
A ASME Pressure Vessel Codes
E PED Pressure Vessel Codes
G GB Pressure Vessel Codes
Q Special Quote
CLR
Cooler
(PIN 43)
X Standard Cooler Required
R Remote Cooler Required
PIN44 PIN 44
G Flow Switch >= 10% Glycol
W Flow Switch < 10% Glycol
COILS
Coils
(PIN 45)
X Aluminum Coils
P Post Coated Dipped Coil
T Post Coated Microchannel Coils
HEAT
Heat Recovery
(PIN 46)
X No Option required
H Heat Recovery
Q Special Quote
FANMOTORS
Fan Motors
(PIN 47)
X TEAO Fan Motors
Q Special Fan Motors required
ENCL
Enclosure Panels
(PIN 48)
X No Enclosure required
1 Wire (Full Unit) Encl Panels (factory)
2 Wire (Full Unit) Encl Panels (eld)
3 Wire/Louvered Encl Panels (factory)
4 Wire/Louvered Encl Panels (eld)
5 Louvered (Cond only) Encl Panels (factory)
6 Louvered (Cond only) Encl Panels (eld)
7 Louvered (Full Unit) Encl Panels (factory)
8 Louvered (Full Unit) Encl Panels (eld)
Q Special Enclosure Panels
ACOUSTIC
Acoustic Blanket
(PIN 49)
X No Acoustic Blanket required
Q Special Acoustic Blanket required
SRDOCS
SR Documents
(PIN 50)
X No Documents Required
A Base, Material & Witness Documents
B Base Document
M Base & Material Documents
W Base & Witness Documents
Q Special Quote
TABLE 2 - COMPLETE PIN NUMBER DESCRIPTION (CONT’D)
