Quantech QTC3150THE User Manual

49
QUANTECH
FORM QTC3-NM1
ISSUE DATE 08/03/2022
SECTION 5 – TECHNICAL DATA
55
REFRIGERANT R-410A
QTC3
HIGH EFFICIENCY UNITS
120THE 129THE 150THE 170THE 205THE 225THE
NOMINAL RATINGS
**
TONS
117.8 126.1 144.5 172.5
194.5 220.6
KW INPUT 122.0 149.6 153.0 194.2 210.9 240.0
EER 10.3 10.1 10.2 9.8 10.1 10.2
IPLV
15.7 16.0 15.5 15.6
16.1 15.2
GENERAL UNIT DATA
Length
187.7 187.7 232.7 232.7
274.4 274.4
Width 88.0 88.0 88.0 88.0 88.3 88.3
Height 94.2 94.2 94.2 94.2 94.2 94.2
Number Of Refrigerant Circuits
2 2 2 2
2 2
REFRIGERANT CHARGE, OPERATING
R-410A, CKT1/CKT2, lb
75/71 76/76 90/82 94/92
95/95 100/100
Oil Charge, CKT1/CKT2, gal 3.33/3.33 4.20/2.80 4.99/3.33 4.99/4.99 4.2/4.2 4.99/4.99
Shipping Weight 5869 6380 7344 7882
9205 9690
Operating Weight
5942 6488 7428 8001
9333 9821
COMPRESSORS, SCROLL TYPE
Compressors Per Circuit
2/2 3/2 3/2 3/3
3/3 3/3
Compressors Per Unit
4 5 5 6
6 6
NOMINAL TONS PER COMPRESSOR
Circuit 1
32 25 32 32
35 40
Circuit 2
32 32 32 32
35 40
CONDENSER
Total Face Area Ft
2
213.8 213.8 267.2 267.2
320.7 320.0
Number Of Rows 1 1 1 1 1 1
Fins Per Inch
20 20 20 20
20 20
CONDENSER FANS, LOW SOUND
Number Of Fans, CKT 1/CKT 2
4/4 4/4 6/4 5/5
6/6 6/6
Fan, hp 2 2 2 2 2 2
Fan, rpm 1160 1160 1160 1160 1160 1160
Total Chiller, cfm
120000 120000 150000 150000
180000 180000
EVAPORATOR
Water Volume, gal
8.8 13.2 10.0 14.3
12.6 14.3
Maximum Water Side Pressure, psig 150 150 150 150 150 150
Maximum Refrigerant Side
Pressure, psig
450 450 450 450 450 450
Minimum Chiller Water Flow Rate, gpm 100 150 150 150 230 230
Maximum Chiller Water Flow Rate, gpm 385 625 625 625 625 650
Water Connections Size, in.
4* 4* 4* 4*
5 5
* Side extension kit (standard), evaporator nozzle remains 3 in.
** Rated in accordance with AHRI Standard 550/590 at an air on condenser temperature of 95°F and a leaving chilled water temperature of 44°F.
NOTE: Additional rating information can be provided by your local Quantech technical support.
TABLE 6 - PHYSICAL DATA (ENGLISH) 60 HZ (CONT’D)
PHYSICAL DATA QTC3040T – QTC3225T 60 HZ

Quantech QTC3150THE Specifications

General

Brand	Quantech
Model	QTC3150THE
Category	Chiller
Language	English
